Oil Water Seperator - 3.5m3/min

MADDINGTON, WA - Delivers Nationally

Oil Water Seperator - 3.5m3/min :      $625 AUD ($688 Inc. GST)

  • Specifications
    Condition:
    New
    No. in Stock
    2
    Year:
    2020
    Make:
    Boge
    Description

    Condensate Cleaner

    Oil/water separator CC 4-2

    Condensate is formed in each compressor. Since the condensate of oil-lubricated compressors
    becomes mixed with oil, it must be treated before disposal. Particularly with modern synthetic
    compressor oils, the gravity separation used up to now does not work optimally. The BOGE
    CC... -2 oil-water separators reliably separate all types of oil, so that a residual oil content
    of less than 10 ppm is achieved.
    Each CC..-2 is certified according to DIBt and fulfils the requirements of the
    German Federal Water Act (Wasserhaushaltsgesetz, WHG).

    Suitable for all oils
    – Due to the tendency of modern fully synthetic oils, which are increasingly used in compressors,
    to emulsify in the condensate, conventional gravity separation of oil and water is not ideal for
    this purpose. The good news is that BOGE CC..-2 are able to meet this challenge and are
    approved for use worldwide.


    Technical Data:
    Volume flow of connected upstream
    BOGE compressors max. 3,50 m³/min
    Receiver volume 3,5 litres
    Condensate intake (hose) 2x G 1/2
    Water discharge (hose) 1x G 1/2
    Permissible condensate temperature +5...+60 °C
    Width / Depth / Height 392 / 211 / 384 mm
    Weight empty 7,4 kg
